Installation instructions - ULTIMA PVC tiles
Comprehensive guide to easy, durable, error-free installation
🧰 Tools required
Before you begin, prepare :
- Non-marking rubber mallet
- Chalk or laser for tracing
- Jigsaw or circular saw (or shears, guillotine, cutter
with concave blade) - Straight edge + protective gloves
🌡️ Pre-installation preparation
To guarantee perfect installation:
- Allow tiles to acclimatize for 24 hours at room temperature (ideally 12-20°C).
- Clean and smooth the surface (vacuum + levelling if necessary)
- Lay tiles flat in the room
- Draw your A-A and B-B lines with chalk or laser
🧱 Standard installation
✅ General steps
- Start with the center of the room
- Fit tiles together without forcing, always square.
- Leave an expansion gap of 5 mm with any fixed point
- Finish cuts last
🧩 ULTIMA installation with visible joints
- Start at center
- Draw lines A-A and B-B (right angles)
- Lay in line, mallet on outer → corners
- Respect expansion space
🕳️ ULTIMA invisible joint installation
- Measure 20 cm from each end of the wall
- Lay the first tilesperfectly straight
- Clip from right to left, hidden dovetail above
- Finish with peripheral cut-outs (5 mm clearance)
⚠️ Glue-down installation recommended if :
- Strong heat or direct sunlight (southern exposure, shop windows)
- Areas with heavy traffic or tight maneuvers (pallet trucks, heavy forklifts)
- Proximity to a heat source (oven, heater, etc.)
🧼 Cleaning & maintenance
- Sweep before machine passage
- Use a suitable scrubber-dryer
- Follow ULTIMA maintenance protocol
⚠️ Further information
Tire stains
Some rubbers may stain (chemical reaction).
Option: anti-staining polyurethane treatment (factory application).
UV stability
❌ Not suitable for outdoor use / prolonged exposure to sunlight.
Batch control
Each order comes from a single batch. Subsequent orders may show slight variations in color.
